Traxxas
Discontinued - E-Revo VXL Brushless Orange and Blue 1/10 Scale 4WD Brushless Electric Monster Truck with TQi 2.4GHz Traxxas Link Enabled Radio System Velineon VXL-6s brushless ESC (fwd/rev) and Traxxas Stability Management (TSM)
Discontinued - E-Revo VXL Brushless Orange and Blue 1/10 Scale 4WD Brushless Electric Monster Truck with TQi 2.4GHz Traxxas Link Enabled Radio System Velineon VXL-6s brushless ESC (fwd/rev) and Traxxas Stability Management (TSM)
Regular price
$549.95 USD
Regular price
$0.00 USD
Sale price
$549.95 USD
Unit price
per
Couldn't load pickup availability
-
ProGraphix® Body
- Clipless body mounting system
- Tough internal frame
- Adjustable rear wing
- External reinforcement for rollover protection
-
VXL-6s™ Waterproof Electronic Speed Control
- 6s LiPo compatible
- Integrated cooling fan
- Real-time telemetry via Traxxas Link
- Machined heat sink
- 3-LED status indicators
- Powered accessory ports
- 10-gauge silicone wire
-
Velineon® Brushless Motor
- 4-pole 2200kV
- 5 mm output shaft
- Finned can for better heat dissipation
-
Traxxas Stability Management® (TSM)
- Includes exclusive Self-Righting capability
- Improves straight line acceleration and braking on low-traction surfaces
- Never dulls throttle or slows the truck
- Adjusts from off to 100% assistance from the transmitter
-
Steering
- High-throw bellcrank steering design
- Dual waterproof digital 2075 servos for 250 oz.-in. of torque
-
TQi™ 2.4GHz Radio System
- 2-channel transmitter
- 5-channel micro receiver (#6533) with fail-safe security and integrated telemetry ports
- Compatible with optional TQi Traxxas Link Wireless Module (#6511) to access full Traxxas Link app functionality (sold separately)
- Automatically stores and loads settings for up to 30 Traxxas Link enabled models
- Adjustable steering and throttle sensitivity (exponential)
- Adjustable steering and throttle endpoints
- Patented waterproof receiver box with easy-access plug
-
Chassis
- Reinforced composite tub for greater durability
- Vented internal battery compartments with quick-release doors
- Low-CG design for improved handling
- Tough skid plates for driveline protection
-
Transmission
- Mod-1 pinion and spur gears
- Fixed gear mesh system
- Torque-Biasing Center Drive
- Cush Drive (no slipper clutch)
- 5 mm aluminum motor plate
-
Drivetrain
- Maxx-Spec™ steel CV driveshafts
- 8 mm steel stub axles
- Heavy-duty telescoping center driveshafts
-
Differentials
- Heavy-duty sealed 4-gear design
- Redesigned bulkheads with underside access
- Maxx-Spec™ ring and pinion gears
- Large 8 mm output shafts
- Steel drive cups
-
Suspension
- Oil-filled GTR shocks with height-adjustable threaded aluminum bodies
- Inboard rocker arm suspension design for extreme articulation
- Low-CG design improves handling and protects components
- Upgraded heavy-duty axle carriers with oversized bearings
- Heavy-duty rocker arms and rod ends
-
Wheels and Tires
- Aggressive Talon™ EXT all-terrain tires
- New tire construction resists ballooning
- Tough 3.8” black wheels
- Splined 17 mm blue aluminum axle hubs
- Sealed Ball Bearings
- Hex hardware with Rust-Resistant Black Oxide Coating
- Requires Battery and Charger (Sold Separately)
Model Specs
| Model Name: | E-Revo VXL Brushless |
|---|---|
| Model Type: | Monster Truck |
| Model Speed: | 70+ mph |
| Model Skill Level: | 3 |
| Scale: | 1/10 |
| Weight: | 11.2 pounds (5.08 kg) |
| Length: | 23.05 inches (585 mm) |
| Width: | 18.32 inches (465 mm) |
| Front Track: | 18.32 inches (465 mm) |
| Rear Track: | 18.32 inches (465 mm) |
| Height: | 8.7 inches (221 mm) |
Motor Specs
| Motor Name: | 2200 kV |
|---|---|
| Motor Type: | Sensorless brushless |
| Motor Weight: | 14.32 ounces (406 g) |
| Motor Length: | 2.97 inches (76 mm) |
| Motor Diameter: | 1.65 inches (42 mm) |
| Motor Shaft Size: | 5 mm |
| Motor Connector Type: | 6.5 mm bullet |
ESC Specs
| ESC Name: | Velineon® VXL-6s |
|---|---|
| ESC Type: | Brushless |
| ESC Case Size: | 2.28 inches (58 mm) / 2.83 inches (72 mm) / 1.81 inches (46 mm) |
| ESC Weight: | 7.30 ounces (207 g) |
| Motor Connectors: | 6.5 mm bullet |
| Battery Connectors: | Traxxas High Current Connector |
